AM 115T Translucent Silicone Rubber – 5 Gallon Kit

$1,393.00

Same Day Shipping: Orders Placed Before 2pm PT M-F

Canadian Customers click here for shipping details.

AeroMarine Products AM115T Silicone Mold making Rubber is a translucent, two-component, room temperature condensation tin-cured silicone material.
AM115T is an excellent choice for moldmaking of intricate patterns and applications where a lower durometer and dimensional stability are required.
AM115T is particularly useful when you need to see “inside” a mold when cutting a parting line.
AeroMarine AM115T Silicone Moldmaking Rubber can be made thixotropic (brushable) by adding our Silicone Thickener.
You can color AM115T with any tin based silicone pigments.
AM 115T’s mix ratio is 10:1 by WEIGHT—you must use a digital gram scale for accurate measurements!
The 5 gallon size weighs 49 lbs and has a 15 Shore A durometer.

DESCRIPTION
HOW-TO
SHIPPING & RETURNS
PURCHASE NOW
TDS

PRODUCT DESCRIPTION

Features:

High tear strength
Translucent (so the master part can be seen inside of the mold)
Excellent dimensional stability
10:1 ratio by weight
6 month shelf life when stored in cool dry place, out of sunlight, and in original containers

DO NOT USE ON HUMAN OR ANIMAL SKIN!

Main Applications:

Molds with complex parting lines
Molds for polyurethane, epoxy resin, and polyester castings
Molds for technical articles and prototypes
Molds for replicating skin effects/animatronics—DO NOT use on human skin!

Properties:

Uncured Properties:

Component A:
- Appearance: Translucent
- Viscosity, cps: 18,000
Component B:
- Appearance: Clear
- Viscosity, cps: 200

Catalyzed Properties (10% cat):

Specific Gravity: 1.08
Pot Life: ~45 Minutes
Tack-free Time: 8-12 Hours
De-mold Time: 16-24 Hours.

Typical Cured Properties (3 days @ 25C):

Durometer: 15A
Tensile Strength, psi: 503 psi
Elongation, %: 605%
Tear B, ppi: 120 ppi
Linear Shrinkage: 0.002 in/in
Useful Temperature Range: 50F to 450F

Material Compatibility:

This product works with most Epoxy and Urethane resins on the market today, however due to the wide variety of products with different chemistries and formulations, we cannot guarantee that it will work with all of them. Some epoxy resin products will not cure when they come in contact with TIN CURE silicone resin and can only work with Platinum Cure silicone. If you are not sure about your epoxy product’s compatibility with this material, please contact the vendor of your epoxy and ask them about compatibility with Tin Cure silicone, or perform a small test before engaging on a major project.

HOW-TO:

Preparation:

Recommendations: Use a vacuum to de-gas this product before use under pressure. Vacuum AM115T for 2-3 minutes (29 inches of mercury). Leave enough room in the container for AM115T to expand. Allow an additional 24 hours before using the mold to let the mold to develop its maximum mechanical strength.
You will need an original part, clean mixing containers, mixing utensils, and a mold box into which to place your piece while making your mold.
A mold box can be made out of almost anything, including a reusable food container, cardboard, wood and/or Legos.
You may also need a digital scale, a glue gun and/or non-sulfur based clay.
Depending on the size of the part, 1/2″ of silicone mold-making rubber is the minimum thickness necessary for the walls of your mold.
Making it too thick will reduce the flexibility of the mold; while too thin will reduce the resistance to tearing.
Silicone RTV mold making rubber may soak into a porous surface like wood or plaster. To prevent sticking, first seal the part with a sealant appropriate to the material.

Types of Molds:

BLOCK mold, one piece. The part usually has no negative draft or undercuts. Building this mold is simple. Mount your part in the center of a container or mold box. You will need at least ½ inch of silicone on all sides of the part. Apply mold release, if needed. Next, pour your mixed silicone in the shallowest area of the container. Pour only into this spot and let the silicone flow naturally around the part. This reduces air bubbles in the silicone. Once the silicone has cured, you can de-mold your part.

BLOCK mold, multiple pieces. This part has undercuts and/or is complex. The mold must be taken apart to remove casing. You can make this type of mold using non-sulfur, non-drying modeling clay and pouring the silicone in 2 separate pours. Use a mold release between the pours to keep the silicone from sticking to itself. To keep the cured mold together, you can use rubber bands or painter’s tape.

Measuring & Mixing:

Shake the catalyst very vigorously for 60 seconds before weighing it.
Weigh parts A and B accurately.
Once you have correctly measured both parts, mix parts A and B together with a plastic or wooden stirring utensil.
Take care to scrape the sides and bottom of the mixing container.
Keep your stirring utensil on the bottom of the container to reduce the amount of air being mixed into the silicone.
Because this silicone and catalyst are the same translucent color, it is a good idea to continue mixing and scraping the sides of the container for a few more minutes after you think it is well mixed.

Pouring Silicone:

When pouring your silicone, do NOT pour it directly onto the part. Instead, pour the silicone into the shallowest part of the mold and let it find its own level. This method prevents air bubbles forming on the surface of your part.
Storing Your Cured Silicone Mold (Storage longer than 1 week)
- First, apply mold release to your cured mold.
- Second, pour your casting material into the prepared mold. Or, you can insert a previously cast cured piece into the prepared mold.
- Third, put your mold (if a smaller mold) with the piece in it into a doubled “Ziploc” type bag with all the air pressed out of the bags.
- Fourth, seal the bags tightly closed using either a plastic bag sealer or over-tape them with duct tape.
- For larger molds, use very heavy duty doubled garbage bags, remove all the air and seal tightly either with a plastic bag sealer or over-tape with duct tape.
- Finally, put your sealed, bagged mold into a plastic storage container with a lid, close the lid and store on a flat shelf/surface (NOT the floor or window) at continuous 70F out of direct sunlight.

Cleaning Your Silicone Mold:

Wash your cured silicone mold with warm/hot water and mild liquid dish soap.
Pat dry thoroughly and then let the mold air-dry fully.
Never use any type of abrasive soap, cleaner or pad to clean your silicone mold!

Tips:

Mold Release:
- Generally, silicone RTV mold making rubber does not stick to anything, and nothing will stick to it. The exception is that it will stick to itself, other silicones, silica, and glass. Mold release will prolong the life of your mold because it reduces the wear on the mold by making it easier to remove your cast piece.

Technical Data Sheets (TDS)

Download
