PCB & Circuit Board Potting Compounds

“”

Circuit Board Potting FAQs:

How do I use potting compounds for circuit boards?

Applying circuit board potting compound to a circuit board can be done in a few simple steps. When using AeroMarine Products’ Potting Compounds, follow these steps:

• Step 1: Gather all necessary equipment, including mixing cups, a metal or plastic stirring utensil, nitrile gloves, potting compound, breathing apparatus or respirator, and your circuit board.
• Step 2: Measure out by volume equal parts A and B into separate clean plastic containers and pour into a third mixing container. Stir with a metal or plastic stirring utensil.
• Step 3: Pour the mixed potting compound into a second mixing cup and mix again to ensure the chemicals are fully combined. (This step can be skipped when using the Urethane Potting Compound)
• Step 4: Slowly pour your potting compound into one corner of the mold or case of your circuit board. The product will spread on its own which will help prevent air bubbles.
• Step 5: Allow your circuit board potting compound to cure, typically 24 hours, although the cure time can be longer if only a small amount of material is used.

Why do I need potting compound for circuit boards?

There are many reasons why you should use a potting compound for circuit boards, including:

• Prevent failing: If you’re working in a high-volume production facility, potting can prevent substrates from getting damaged in harsh environments from vibrations and shock.
• Increased performance: Potting creates a shield over the circuit board, which improves electrical performance.
• Heat dissipation: For conductive electrical appliances, potting compound will allow heat to dissipate throughout the material.
• Vibration Reduction: If you have strong mechanical machines that can cause impact damage or abrasion, potting can dampen vibrations to keep your electrical components intact.
• Privacy: If you’re selling a product, you can use black potting compound to provide privacy and security to your circuit board or product to prevent reverse engineering.

Which material is best for circuit board potting?

It depends on what you are wanting to achieve with the potting material. The best material for circuit board potting that is the most difficult to remove and provides the hardest cover is epoxy. Epoxy resins insulate circuit boards to protect them from harsh environments, such as moisture, corrosive agents, and chemicals. Epoxy resin is also temperature resistant and offers great adhesion, so you can ensure your circuit board is completely protected. Using circuit board potting compounds, such as Aeromarine Products’ Epoxy Dielectric Potting Compound, will perfectly encapsulate electronic circuits to provide a dielectric barrier.

If you want the circuits to be resistant to shock and vibrations in great depths under water our Underwater Urethane Potting Compound is the most effective.
